>YAMAKIN CO., LTD.

LED CURE Master

Technology
Specifications
Leaflet

Technology

1. Reduced Costs

Long-lasting LED lamps reduce running costs and concern about lamps malfunctioning during the curing process.

2. Lower Electricity Consumption(160VA)

The electricity consumption is about 1/5 of halogen lamps*. This suits today’s energy–conscious operating environment. *Compared with Denken Brand products.

3. Shorter Curing Time

Curing composite resin, Luna-Wing and TWiNY can be cured in a much shorter time. Curing time is shortened from about 10 minutes to 2 minutes 30 seconds. The total time required for all stages of light curing for one time each (Curing Invisible Opaque, Opaque, Dentine, Enamel and Final Curing) is reduced from 570 sec. to 150 sec.

Curing time for Luna-Wing and TWiNY

	LED CURE Master	conventional curing time
Invisible Opaque	10seconds	90seconds
Opaque	30seconds	180seconds
Body （Dentine, Enamel, etc）	10seconds	60seconds
Base	90seconds	180seconds
Stain	10seconds	60seconds
Final Light Curing	90seconds	180seconds

Operations Course Buttons for Luna-Wing and TWiNY

		Dry time	Curing time	Course Button
Invisible Opaque		-	10seconds	1
Opaque		-	30seconds	2
Body （Dentine, Enamel, etc）		-	10seconds	1
Base		-	90seconds	3
Stain		-	10seconds	1
Final Light Curing	Luna-Wing	-	90seconds	3
Final Light Curing	TWiNY	60seconds	90seconds	4

*The LED CURE MASTER can be used for curing not only composite resin, but also materials for surface treatment, such as self-adhesive glossy protective coating material.
*The curing process length can be customized in units of seconds.

4. Stable Light Volume

Light volume does not fluctuate, thanks to the use of constant current circuit; therefore, curing can be performed evenly and stably.

5. No Heat and Less Shrinkage

Since the LED CURE MASTER does not emit heat waves, composite resin does not shrink or become deformed; as a result, it is suitable for precise dental operations such as building up implant superstructures.
